Name: fiber optic rotary joint, SM IP68 or mm, 200million revolutions, optical slip ring LPFO-01B
Brand: fiber optic rotary joint, SM IP68 or mm, 200million revolutions, optical slip ring LPFO-01B
SKU: LPFO-01B
Rating: 4.5 (166 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

Model Number: LPFO-01B

Type: Electronic Accessories

Maximum Speed: 2000rpm

Insertion Loss: <2dB

Max Optical Power: 23dBm

Working Temperature: -45~+80â„ƒ

Basic Infomation

Model Number: LPFO-01B

Payment & Shipping Terms

Product Description

Bargain Price Only in Alibaba

Fiber Optic Rotary Joint, also known as fiber optic slip ring, fiber optic rotary connector, optical hinges, etc. This slip ring adopts optical fiber as media for transmitting data, providing the best technical solution for elements of system to transmit data when rotating. It is especially suitable for equipments that require unlimited, continuous or intermittent rotation and transmit large capacity of data and signals from stationary position to rotary position. It can improve mechanical performance, simplify system operation, and avoid damage to fiber optic due to rotation of moving joints. The fiber optic rotary joints can be used with a traditional electric slip ring as a photoelectric hybrid slip ring to transmit power and high speed data.

Specifications
Fiber types	SM or MM	Maximum speed	2000rpm or more
Channel number	1	Package style	Pigtails on both ends
Wavelength range	SM:1270-1650nm MM:650-1300nm	Weight, approx	10g(No tail cable and connection included)
Insertion loss	<2dB	Jacket types	0.9/2/3mm (Kevlar/TPU or Armor)
Insertion loss ripple	<0.5dB	Connector types	FC/SC/ST/LC(PC or APC)
Return loss	≥40dB(SM) ≥30dB(MM	Estimated life cycle	>200 million revolutions
Max Optical power	23dBm	Vibration	MIL-STD-167-1A
Working temperature	-45~+80℃	Mechanical shock	MIL-STD-810G
Storage temperature	-55~+85℃	IP rating	IP65 or IP68

Advantages:

No contact and friction, long life, up to 10 million rpm (more than 100 million rpm for signal channel )
Can combine with multiple signals such as video, series, and Ethernet signal, etc.
Use optical fiber to transmit information, no leakage, no electromagnetic interference; can transmit tens of hundreds of kilometers of networking applications over long distances
The transmission bandwidth is much larger than the electrical connector, and it can be used to double the bandwidth with the wavelength division multiplexer.
Small in volume and light in weight that is easy to integrate with electric slip ring, and system is easy to upgrade and change
Providing the world's smallest single-channel fiber optic rotary joint, as well as double-channels, four-channels, ten-channel or even more channel for your option
Providing photoelectric integrated rotary joint

Options

Fiber optic transmission type is optional, circuits of current and signal are optional.
Single mode or multi mode, single channel or multiple channel
Shape can be customized, housing material and driving connector are optional as well

Typical Application

Robotics
Material conveying system
Rotating turret on the vehicle
Remote control system
Radar system
Offshore and marine system
High speed video, digital, analog signal transmission and control of optic fiber sensor revolving table
Medical system
Video surveillance system
National or international security systems
Subsea operating systems

Outline

Installation Instructions

Features of LPFO Fiber Optic Rotary Joints

(Independent Research and Development)
